GV-MFD320 Geovision 3 Megapixel IP Camera, Mini Dome, H.264, Micro SD
3 Megapixel IP Camera



Alternative Views:


Geovision GV-MFD320

3 Megapixel IP Camera

Geovision Camera Spec
Geovision GV-MFD320 3 Megapixel IP Camera Specification

Our Price: $369.99


Availability:: Usually Ships in 24 Hours
Product Code: GV-MFD320

Description


Please Note: The Geovision GV-MFD320 is no longer manufactured by Geovision, please refer to the Geovision GV-MFD3401-1F.

This camera can run dual video streams of each H.264, MPEG-4 or MJPEG. A built-in microphone enables audio monitoring and recording in addition to video. The Geovision GV-MFD320 can record locally using the Micro SD / SDHC card slot (Geovision recommends using class 6 or above).

This camera can be powered locally by 12V-DC or by POE over a Cat-5 Ethernet cable. The Geovision GV-MFD320 can be accessed through the web interface in addition to iPhone, iPad, Android and 3GPP mobile devices.

Geovision GV-MFD320 Features

  • 1/2.5" progressive scan CMOS image sensor
  • This model is not recommended for Audio Applications, please refer to the GV-MDR320
  • 2.54mm Fixed Megapixel Lens
  • Dual video streams from two of H.264, MPEG4 and MJPEG
  • Up to 20 fps at 2048 x 1536
  • 12V-DC or POE Compatible
  • Includes 32 Channel Geovision NVR Software
  • View from iPhone, iPad, Android and 3GPP mobile devices
  • Built-in microphone
  • Privacy mask
  • Motion detection
  • Micro SD / SDHC
  • Tampering alarm
  • 31 Language web interface

Mounting Positions / Dimensions

Geovision GV-MFD320 Dimensions Geovision GV-MFD320 Dimensions Geovision GV-MFD320 Dimensions

Click on the images above to enlarge.


32 Channel Geovision Software

Each Geovision camera includes a free 32 channel software license which can be used with any Geovision IP camera. Install the software on a Windows computer and create a PC based surveillance DVR / NVR for your Geovision cameras. Click here to view the latest Geovision software specification.

Remote Viewing Support

Geovision includes many options to view your cameras remotely over a local network and also remotely over the Internet. Remote viewing is supported by both Windows and Mac based PCs. Geovision also includes support to view cameras from cell phones and other mobile devices including: iPhone, iPad, iPod Touch, Android, Blackberry, Windows Mobile, Symbian, and other 3G / 3GPP cell phones. Geovision provides free apps for all of these types of devices. Some remote viewing methods require use of the NVR software that is included with the camera and some methods can connect directly to the camera and do not require a PC be used. Click here for more information on Geovision remote viewer options.

Geovision Remote View


PoE for IP Camera

This IP camera is PoE (power over Ethernet) compliant which allows the installer to run a single CAT-5e cable to provide both power and data connectivity to the camera. CCTV Camera Pros supplies the following PoE injectors and PoE network switches which are compatible with this camera.

Single Port PoE Injector
4 Port PoE Switch
4 Camera PoE
8 Port PoE Switch
8 Camera PoE
16 Port PoE Switch
16 Camera PoE

Please refer to these diagrams, to learn more about how to wire IP cameras using a PoE injectors or a PoE switch.
