Please Note: The Geovision GV-MFD130 is no longer manufactured, please refer to the Geovision GV-MFD1501-1F.
The Geovision GV-MFD130 Fixed Dome IP Camera features an image resolution of
1280 x 1024 at up to 30 frames per second. The Geovision GV-MFD130 Fixed Dome IP Camera has the ability to run dual video streams of each H.264, MJPEG or MPEG-4.
It has a
2.54mm fixed megapixel lens with a 1/3" progressive scan CMOS image sensor. The Micro SD / SDHC card slot enables the GV-MFD130 to record locally instead of over a network. The Geovision GV-MFD130 can be powered locally by 12V-DC or by POE over a Cat-5 Ethernet cable.
A built-in microphone allows the camera to monitor and record audio. It can be accessed through the web interface as well as
iPhone, iPad, Android and 3GPP mobile devices.
Geovision GV-MFD130 Features
-
1/3" progressive scan CMOS image sensor
- This model is not recommended for Audio Applications, please refer to the GV-MDR120
-
2.54mm Fixed Megapixel Lens
-
Dual video streams from two of H.264, MPEG4 and MJPEG
-
Up to 30 fps at 1280 x 1024
- 12V-DC or POE Compatible
-
Includes 32 Channel Geovision NVR Software
-
View from iPhone, iPad, Android and 3GPP mobile devices
- Built-in microphone
- Privacy mask
- Motion detection
- Micro SD / SDHC
- Tampering alarm
- 31 Language web interface
Mounting Positions / Dimensions
Click on the images above to enlarge.
32 Channel Geovision Software
Each Geovision camera includes a free 32 channel software license which can be used with any Geovision IP camera. Install the software on a Windows computer and create a PC based surveillance DVR / NVR for your Geovision cameras. Click here to view the latest
Geovision software specification.
Remote Viewing Support
Geovision includes many options to view your cameras remotely over a local network and also remotely over the Internet. Remote viewing is supported by both Windows and Mac based PCs. Geovision also includes support to view cameras from cell phones and other mobile devices including: iPhone, iPad, iPod Touch, Android, Blackberry, Windows Mobile, Symbian, and other 3G / 3GPP cell phones. Geovision provides free apps for all of these types of devices. Some remote viewing methods require use of the NVR software that is included with the camera and some methods can connect directly to the camera and do not require a PC be used. Click here for more information on
Geovision remote viewer options.
PoE for IP Camera
This IP camera is PoE (power over Ethernet) compliant which allows the installer to run a single CAT-5e cable to provide both power and data connectivity to the camera. CCTV Camera Pros supplies the following PoE injectors and PoE network switches which are compatible with this camera.
Please refer to these diagrams, to learn more about
how to wire IP cameras using a PoE injectors or a PoE switch.
